DN125消防水箱管道波纹减震接头
Fire bellows shock absorber joint

上海淞江减震器集团有限公司官方网站为您介绍：DN125消防水箱管道波纹减震接头信息，淞江集团为众多消防工程配套波纹减震接头产品，改产是由不锈钢生产的波纹，该波纹具有良好的减震效果和轴向位移补偿作用，可以有效的保护消防水箱管道的长期使用寿命。
Shanghai Songjiang absorber group limited official website for your introduction: DN125 fire water tank bellows joint damping information, Songjiang group for a number of fire engineering supporting corrugated joint damping products, the production is made of corrugated stainless steel production, the bellows has good damping effect, long can effectively protect the fire water tank.

制造商：上海淞江减震器集团有限公司

Name: DN125 fire tank corrugated shock absorber joint

Caliber: DN125mm

Pressure: PN16

Wave number: 8 wave

Thickness: 0.8mm

Length: 230mm

Scalability: 50mm

Corrugated material: stainless steel 304

Flange material: carbon steel (forging)

Brand: Songjiang group

Manufacturer: Shanghai Songjiang shock absorber Group Co., Ltd.

了解该产品参数信息请点击：【样册P93】BGF型 不锈钢波纹补偿器

材料说明：

水箱波纹减震接头管体：为了更持久的使用寿命，全部采用不锈钢304正材生产，支持各种光谱仪检测，假一赔十，厚度全部厚于同行业标准。

连接法兰：法兰全部采用山西正宗锻打材质，无论是强度还是密封性都是很好的材质，不要拿市面上的铸钢、钢板钢法兰来对比，没有任何可比性。

焊材：焊材全部采高于母材等级标准，让焊接点更加牢固。

限位耳板：耳板全部采用加大加厚尺寸生产，每个型号都可以与同行业同型号去一对一的对比，这就是所谓的没有对比就没有伤害。

限位螺杆：螺杆全部采用8.8级高强度镀锌，为100%确保产品的综合强度，不要与市面的4.8级来对比，无意义。

生产标准：淞江集团通过德国莱茵TUV认证，并且严格按照压力管道生产要求进行生产，让出厂的每一个水箱波纹减震接头产品达到100%的合格。

Material description:

Bellows body: for longer, all stainless steel 304 material is used to support all kinds of spectrometers, and the fake one is ten, the thickness is all thicker than the same industry standard.

Connecting flange: all flanges are made of orthodox forging material in Shanxi, both strength and sealing are the best materials. Do not compare the cast steel and steel plate flange on the market with no comparability.

Welding consumables: welding materials are higher than the level of the parent material standard, let the welding point more firmly.

Limit ear plate: ear boards are all made by increasing thickening dimensions, each model can be compared with the same industry's one type to one to one, which is called no contrast, no harm.

Limit screw: the screw is all 8.8 - grade high - strength zinc plating, which is * to ensure the comprehensive strength of the product, not to compare with the market level 4.8.

Production standard: Songjiang group passes the national pressure pipe production license requirement, TS number: TS2731B90-2020, and is strictly controlled according to the production requirement of TS pressure pipe, so that every corrugated compensator product of factory reaches * qualified.
